CORIO C-B13 Open Heating Bath Circulators with stainless steel bath tank

Laboratory circulators for internal temperature application at working temperatures from +20 to +100°C

The Open Heating Bath Circulators of the new CORIO series feature high-quality bath tanks made of stainless steel.

Request a quote
Data at mains voltage / frequency:
230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
C-B13
Order No. 9 011 413.22
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 0.8 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.22
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 0.8 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.22
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 1 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.22
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 1 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.33.chn
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.33.chn
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.33
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.33
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.04
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.04
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.05
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm
C-B13
Order No. 9 011 413.05
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Heating capacity 2 kW
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Filling volume 9 ... 13 l
Dimensions
(W × L × H)
38 x 40 x 42 cm

Product Features

  • Integrated drain screw
  • Models for internal applications
  • Very quiet
  • High-quality bath tanks made of stainless steel
  • Integrated drain screw (except B5)
  • Precise temperature control
Dimensions and volumes
Dimensions
(W × L × H)
38 x 40 x 42 cm
Filling volume 9 ... 13 l
Weight 8.2 kg
Temperature values
Working temperature range +20 ... +100 °C
Temperature stability ±0.03 °C
Setting the resolution of the temperature display 0.1 °C
Temperature display resolution 0.01 ... 0.1 °C
Ambient temperature +5 ... +40 °C
Data at mains voltage / frequency:
230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Performance values
Heating capacity 0.8 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 0.8 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 1 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 1 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Performance values
Heating capacity 2 kW
Viscosity max. 1 cST
Circulation capacity flow rate 6 l/min
Bath
Bath tank Stainless steel
Usable bath opening
(W x L / D)
30 x 18 / 15 cm
Cooling
Cooling coil accessory
Other
Classification
according to DIN12876-1
Classification I (NFL)
IP Code
according to IEC 60529
IP 21
Pump type Immersion Pump
Electronics
Temperature control PID1
Absolute temperature calibration 1 Point Calibration
Temperature display LED
Temperature setting Keypad
Available voltage versions
100-115V/50-60Hz Nema N5-15 Plug 9011413.22
230V/50-60Hz CN Plug 9011413.33.chn
230V/50-60Hz Schuko Plug - CEE 7/4 Plug Type F 9011413.33
230V/50-60Hz UK Plug Type BS1363A 9011413.04
230V/50-60Hz CH Plug Type SEV 1011 9011413.05

Heat-up time

chart_hu_corio-c-b13_water
